Stepdown

Draw attention to your Gondola run with a Step Down End Cap. This configuration is ideal for seasonal merchandise that needs to move off shelves quickly. Example features a Contoured End Display, using Shelves and Decks with rounded edges to give your display a softer look.

Stepdown

Draw attention to your Gondola run with a Step Down End Cap. This configuration is ideal for seasonal merchandise that needs to move off shelves quickly. Example features a Contoured End Display, using Shelves and Decks with rounded edges to give your display a softer look.

Gondola End Caps Step Down End Cap Lozier
  • Gondola End Caps Step Down End Cap Lozier
  • Gondola End Caps Step Down End Cap Top View Lozier

Roll over image to zoom in.

Contact to Order
Download PDF Print Email Brochure

How to Order

This End Cap features a combination of Lozier Products.  See below for details.

Contoured End Display

Product Details

Load Rating

  • 600 lbs evenly distributed per deck (13″ – 19″ D)
  • 800 lbs evenly distributed per deck (22 – 25″ D)



  • Same as Wall End Display except includes Contoured End Decks and Contoured Base End Trims.
  • Contoured Shelves also available (ordered separately)
  • Order Gap Filler to close off the bottom rear when unit is wider than the island width.
  • Actual width of unit equals nominal width plus 2″
  • Accepts Accessory Panels and connectors
  • Stabilizers required and ordered separately for Non-Compliant height to depth Contoured End Displays (See Product Safety information for Height to Depth Chart)
  • Contour decks and shelves with only one round corner available for two section displays.
View product details

Product Options and Numbers

COMPONENTS (ORDER SEPARATELY) QTY.
A. Uprite 2
B. Base Bracket (Standard or Heavy Duty) 2
C. Contoured End Deck 1
D. Closed Base Front 1
E. Top Rail 1
F. Center Rail (2 per section 78H-120H) 1 or 2
G. Bottom Rail 1
H. Splicer Rail (Sections 78H-120H) Use 2 top rails for splicer on 2′ and 30″ wide sections. 1
I. Back Material (1 or 2 per side) See Back Chart
J. Contoured Base End Trim (Pair) 1
K. Uprite End Trim 2
Contoured End Displays
    CONTOURED END DISPLAY – SIZES
Depth  Height
48″ 54″ 60″ 66″ 72″ 78″ 84″ 90″ 96″
13″ N/A N/A N/A N/A N/A N/A N/A
16″
 N/A N/A N/A N/A
19″ N/A
22″
25″

Island Section

Product Details

INCLUDES

  • 1 Uprite
  • 2 Base Brackets
  • 2 Base Decks
  • 2 Closed Base Fronts
  • 1 Top Rail
  • 1 Center Rail (2 on 96-144”H)
  • 1 Bottom Rail
  • 1 Splicer Rail (78”-144”H)
  • Back Material



DIMENSIONS

Island Gondola Dimensions



BACK OPTIONS

Pegboard
Pegboard
Marteck
Marteck
Peg Mirror
Peg Mirror
Peg Woodgrain
Peg Woodgrain
Woodgrain
Woodgrain
Slotwall Inserts
Slotwall w/ Inserts
Slotwall
Slotwall
Econo Marteck
Econo Marteck

Save

Save

View product details

Product Options and Numbers

Example Part #:   IS   4   54   19   19   06   S   T   CBF   CHR   PLT   PLT   P   PLT   M   PLT   5   N   PLT   S   N   PLT



Island Section: IS

Section Width:  2’, 3’, 30″,4′

Height: 36”, 42”, 48”, 54”, 60”, 66”, 72”, 78”, 84”, 90”, 96”, 108”, 120”

Base Deck Depth, Side A: 13”, 16’, 19”, 20”, 22”, 25”, 28”, 31” (13″ not available in HD)

Base Deck Depth, Side B:  13”, 16’, 19”, 20”, 22”, 25”, 28”, 31” (13″ not available in HD)

Base Type: 06, LB

Spring Locking Base Bracket: S, HD (Includes HD Base Bracket and HD Uprite)

Rail Type: T, Omit for regular rails (Not available in HD)

Base Front: CBF, OBF

Base Front Color: CHR

Uprite Color: PLT, Optional Catalog Colors

Back Rail Color: PLT, Optional Catalog Colors

Back Material, Side A:  P, M, S, SI, ME, W, PW, PM, NBR

Back Color, Side A: PLT, Optional Catalog Colors

Back Material, Side B:  P, M, S, SI, ME, W, PW, PM, NBR

Back Color, Side B: PLT, Optional Catalog Colors

Deck, Side A: S, HDSD

Deck Molding, Side A: N, M13S, M55S, M35S, MR1S

Deck Color, Side B: PLT, Optional Catalog Colors

Deck, Side B: S, HDSD

Deck Molding, Side B: N, M13S, M55S, M35S, MR1S

Deck Color, Side B: PLT, Optional Catalog Colors

Suffix Key
06 – 06 Base (8″H)
LB – Low Base (6″H)
T – Telescopic Rails
CBF – Closed Base Front
OBF – Open Base Front
CHR – Charcoal Black
PLT – Platinum
S – Standard Deck
HD – Heavy Duty
HDSD – Heavy Duty Deck
Back Options
P – Pegboard
M – Marteck
S – Slotwall
SI – Slotwall with Inserts
ME – Econo Marteck
W – Woodgrain
PW – Peg Woodgrain
PM – Peg Mirror
NBR – No Backs or Rails
Moldings
N – No Molding
M13S – M13 Satin Molding
M55S – M55 Satin Molding
M35S – M35 Satin Molding
MR1S – MR1 Satin Molding

Full Height Merchandise Panel

Product Details

  • Full Height version of Flush Merchandising Panel (accommodates up to a 9″ difference)
  • Panel extends past the Base End Trim and rests on the floor with leveling legs
  • Compatible with all Gondola Back options except Open Backs
  • Not compatible with End Deck

Installation Instructions

View product details

Product Options and Numbers

Example Part #:   FHMP   60   36   06   P   M   PLT   PLT   PLT

Full Height Merchandise Panel: FHMP

Uprite Height: 42”, 48”, 54”, 60”, 66”, 72”, 78”, 84”, 90”, 96”

Width: 24”, 30”, 36”, 48”

Base Type: 06, LB

Exterior Panel Style: P, M, W, PW

Interior Panel Style (if required): M, W

Exterior Panel Standard Finish: PLT, Optional Catalog Colors

Interior Panel Standard Finish (if required): PLT, Optional Catalog Colors

Frame Standard Finish: PLT, Optional Catalog Colors

Suffix Key
06 – 06 Base (8″H)
LB – Low Base (6″H)
P – Pegboard Back
M – Marteck Back
W – Woodgrain Back
PW – Pegboard Woodgrain Back
PLT – Platinum

Wall End Display Gondola Top Rail

Product Details

  • Wall End Display Gondola Top Rail is part of Wall End Display Stabilizer, and is ordered separately
  • Includes hardware pack with Uprite Inserts
View product details

Product Options and Numbers

Example Part #:   WEDGR   48     PLT

Wall End Display Gondola Top Rail: WEDGR

Width: 36″, 48″

Standard Finish: PLT, Optional Catalog Colors

Suffix Key
PLT – Platinum

Wall End Display End Top Rail

Product Details

  • Wall End Display End Top Rail is part of Wall End Display Stabilizer, and is ordered separately
  • Includes hardware pack with Uprite Inserts
View product details

Product Options and Numbers

Example Part #:   WEDER   48     PLT

Wall End Display End Top Rail: WEDER

Width: 24″, 30″, 36″, 48″

Standard Finish: PLT, Optional Catalog Colors

Suffix Key
PLT – Platinum

TL Shelf

Product Details

  • Two position tilt-in Shelf with extended bracket
  • Angular adjustment: flat or 17° downslope
  • Molding accommodates a 1.235″ tag
  • 1/4″ perforations for clip-on accessories
View product details

Product Options and Numbers

Example Part #:   TL   4   19   N   PLT



TL Shelf: TL

Width:  2’, 30″, 3’, 4′

Depth: 7”, 10”, 13″, 15″, 16″, 17″, 19”, 22″, 25″, 28″, 31″

No Molding: N

Standard Finish:  PLT, Optional Catalog Colors

Suffix Key
N – No Molding
PLT – Platinum
 Shelf Depth    Downslope
Flat  17°
7″ 300 lbs 300 lbs
10″ – 25″ 500 lbs 250 lbs
28″ & 31″ 400 lbs 200 lbs

Lbs. evenly distributed

DL Shelf

Product Details

  • Three position, drop-in shelf with extended bracket
  • Angular adjustment: flat, 17° or 30° downslope
  • 1/4″ perforations for clip-on accessories
View product details

Product Options and Numbers

Example Part #:   DL   4   19   N   PLT



DL Shelf: DL

Width:  2’, 30″, 3’, 4′

Depth: 7”, 10”, 13″, 15″, 16″, 17″, 19”, 22″, 25″, 28″, 31″

Molding: N

Standard Finish:  PLT, Optional Catalog Colors

Suffix Key
N – No Molding
 Shelf Depth    Downslope
Flat  17° 30°
7″ 300 lbs 300 lbs 125 lbs
10″ – 19″
 500 lbs 250 lbs 250 lbs
22″ – 25″ 500 lbs 250 lbs 125 lbs
28″ & 31″ 400 lbs 200 lbs 100 lbs

Lbs. evenly distributed.
