S-Series Storage Shelving Sections
Roll over image to zoom in.
Product Details
- One S-Series Storage Uprite Assembly required to finish each continuous run, including single sections
- Order Crossbrace or Closed Back sections based on specifications (see tables below)
- Refer to table below to determine if Regular Duty or HD Crossbraces are needed.
- Can also order Crossbraces and Back separately
- See table below for system load rating
- Note: Back panels provide HD load capacity.
ONE SECTION INCLUDES:
- One S-Series Uprite (Open or Closed)
- Back or Crossbrace (if required – see Stabilization Requirements diagram below)
- Top and bottom Shelf (two Shelves per section)
STABILIZATION REQUIREMENTS DIAGRAM
SECTION CAPACITY
| Vertical Shelf Spacing | Regular Duty (XR) Crossbraces | Heavy Duty (XH) Crossbraces or Back Panel |
| < 24″ | 1,200 lbs | 3,000 lbs |
| 24″ – 36″ | 1,200 lbs | 2,500 lbs |
| 36″ – 48″ | 1,200 lbs | 2,000 lbs |
| 48″ – 60″ | 1,200 lbs | 1,500 lbs |
| > 60″ | Not recommended | Not recommended |
NOTE: Shelving Sections loaded beyond 1,200 lbs require Heavy Duty Crossbraces or Back Panel.
ORDERING INSTRUCTIONS
- Order desired number of S-Series Storage Shelving Sections per the features and options detailed below.
- Order one additional S-Series Uprite Assembly to finish the end of the run.
- Order desired quantity and style of additional Shelves. Two Shelves are included in the Section.
